FastAce Gravitee Fork AHX12RV (3.0) for E-Moto. Surron, E-Ride Pro, Talaria

This is FastAce's newest fork for E-Moto (ALX12RV). Surron Light Bee (LBX), Talaria Sting and Sting R MX3, MX4, and XXX, E Ride Pro SS. Also referred to as the "3.0"; it's bigger and beefier than its predecessor. Has 18 clicks of both high and low-speed compression damping adjustment.

FEATURES:

• Legs Material: 2000 Series Aluminium
• Leg Diameter: 37mm
• Axle: 20*10*M14*P1.5*170L
• Steerer: 1-1/8" Straight
• Spring:  coil spring
• Adjustments: Rebound, HS and LS Compression
• 18 steps High Speed and 18 steps Low Speed Compression Damping
• 18 steps Rebound Damping
• Crown: Forged
• Brake Post Mount: 203mm (compatible with up to 223mm rotors)
• Max Tire Width: 67mm
• Ride Height: 22.9in
• Travel: 200mm



  FastAce's weight scale (approximate):


  • 38lbs-60lbs Progressive spring: 176lb-265lb rider weight (realistically 150-225lb)

  • 60lbs: 220lb-265lb riders weight (realistically 190-225lb)
